Digitus OnLine UPS system, 10 kVA/ 10 kW
10000 VA, 10000 W, Online double converter UPS10 items in stock at supplier
Product details
The DIGITUS® OnLine UPS is a double-conversion UPS solution that offers top-notch power outage protection and continuous power generation in a compact and flexible system. The single-phase UPS operates with high energy efficiency and is ideal for protecting critical infrastructures in both centralized and edge network applications. Scalable runtime options with suitable external battery cabinets provide additional flexibility when longer uninterruptible power supply is required. The user-friendly LCD display and network management capabilities, including configuration, make this system easy to install and maintain. With market-leading efficiency and a consistent power factor, the UPS meets your critical application requirements. The UPS does not have internal batteries; these must be ordered separately as external battery modules.
Model | 19" rack |
Scope of application | Network cabinet, Server room |
Plug type | USB |
Item number | 16648327 |
Manufacturer | Digitus |
Category | UPS |
Manufacturer no. | DN-170107 |
Release date | 15-9-2021 |
External links |
UPS type | Online double converter UPS |
Power output | 10000 W |
Output power capacity | 10000 VA |
Model | 19" rack |
Rack Unit | 2U |
shaft type | Sine wave |
UPS protection functions | Overvoltage protection, Protection for 1000BASE-T, Protection for 100BASE-T, Undervoltage protection |
Scope of application | Network cabinet, Server room |
Plug type | USB |
Connections | Cold-device plug Power In, SmartSlot, USB charging port |
USB ports | USB-C |
input voltage | 276 V |
output voltage | 240V |
Max. input current | 1 A |
Output frequency | 50 - 60 Hz |
Efficiency full load | 94 % |
Efficiency battery operation | 93.50 % |
Operating temperature | 0 - 40 °C |
Max. noise level | 55 dB |
Protection type (IP code) | IP20 |
Battery category | Industry battery |
Battery | Rechargeable battery |
Battery type | Lead–acid battery |
Battery size | Device specific |
Number of cells | 20 x |
Voltage | 120 V |
Charging time | 8 h |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | UPS, UPS device (without internal battery), UPS manual |
Items per sales unit | 1 x |
Height | 86.50 mm |
Weight | 18 kg |
Width | 440 mm |
Length | 620 mm |
Length | 77 cm |
Width | 61 cm |
Height | 21 cm |
Weight | 19 kg |
