Main features:

• WAN connection: Ethernet WAN
• Yes, wireless LAN characteristics
• Top WLAN standard: IEEE 802.11n
• WLAN data transfer rate (max.): 150 Mbit/s
• WLAN standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
• Maximum indoor distance: 100 m
• Maximum outdoor distance: 300 m
• Modulation: 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
• Number of channels: 14 channels

Ethernet LAN characteristics:

• Built-in Ethernet port: Yes
• Interface type: Ethernet LAN
• Fast Ethernet
• Ethernet LAN data transfer rates: 10, 100 Mbit/s
• Cabling technology: 10/100Base-T(X)

Connectors and interfaces:

• Number of Ethernet LAN ports (RJ-45): 1
• DC connector: Yes

Mobile network:

• 3G: No
• 4G: No

Network standard:

• IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
• Port forwarding: Yes

Router protocol:

• RIP-1, RIP-2

Protocols:

• DHCP client: No
• DHCP server: Yes
• Supported network protocols: CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP

Antenna:

• Antenna type: Internal
• Antenna gain level:.
