Short Info: Axis A4020-E Reader - RFID contactless reader - wired - 13.56 MHz - NCS S 9000-N Group Integrated Systems & Automation Manufacturer Axis Communications Manufacturer Art. No. 02144-001 Model A4020-E Reader EAN/UPC 7331021073524

Product Description: Axis A4020-E Reader - RFID contactless reader Product Type RFID contactless reader Environment Indoor, Outdoor Integrated Components Buzzer Card Technology HID MIFARE DESFire EV1, HID MIFARE DESFire EV2, HID MIFARE Classic, HID MIFARE Plus Level 1 Connectivity Wired Frequency Band 13.56 MHz Color NCS S 9000-N Dimensions (Width x Depth x Height) 4.8 cm x 2.7 cm x 12.1 cm

Detailed Information General Product Type RFID contactless reader Environment Indoor, Outdoor Integrated Components Buzzer Connection Technology Wired Card Technology HID MIFARE DESFire EV1, HID MIFARE DESFire EV2, HID MIFARE Classic, HID MIFARE Plus Level 1 Frequency Band 13.56 MHz Interfaces Serial Features Tamper contact, Shock protection, Alarm switch, RGB LED indicator, Scratch protection Open Supervised Device Protocol (OSDP)

Miscellaneous Supplied Accessories 4-pin 26-18 AWG terminal block Product Material ABS Plastic Color NCS S 9000-N Required Power Supply DC 12 V Markings EN 61000-6-1, NEMA Type 4X, EN 300.330, IEC 60068-2-27, IEC 60068-2-6, EN 61000-6-3, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, IP65, EN 62311, IK07, EN 301 489-1, IEC/EN/UL 60950-22, EAL 6+, EN 301 489-3, CAN/CSA-C22.2 No. 62368-1, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 60950-22, ISO/IEC 14443A, ISO/IEC 14443B, IEC/EN 60529 IP65, FCC Part 15 Subpart B Class B, FCC Part 15 Subpart C, IEC/EN 62262 IK07

Dimensions and Weight Width 4.8 cm Depth 2.7 cm Height 12.1 cm Weight 118 g Environmental Conditions Min. Operating Temperature -30 °C Max. Operating Temperature 65 °C Allowed Humidity during Operation 10 - 100 % (condensing).
