Gewiss Ground fault circuit interrupter

Price in EUR including VAT, free shipping
Ratings
BrandMore from Gewiss
Delivered between Wed, 18-6 and Fri, 20-6
Only 2 items in stock at supplier

Product details

Gewiss Residual Current Circuit Breaker GW90923

Manufacturer: Gewiss
Designation: Residual Current Circuit Breaker 63A/30mA 4-pole
Type: GW90923
Number of Poles: 4
Rated Voltage: 400 V
Rated Current: 63 A
Rated Residual Current: 0.03 A
Mounting Type: DIN Rail
Residual Current Type: A
Selective Type: No
Time Delay Type: No
Additional Devices Possible: No
Protection Class (IP): IP20
Width in Division Units: 7

The Restart PRO Autotest Residual Current Circuit Breaker (RCCB) performs an automatic self-test (Autotest) at regular intervals, replacing the need for manual testing. During these tests, the residual current circuit breaker is fully activated without interrupting the power supply to the system. If the RCCB trips, Restart PRO Autotest restores the power supply after conducting an insulation test of the system. In the event of a persistent system fault, no attempt to reset will be made. Every 15 minutes, Restart PRO Autotest conducts a system check. If the system returns to a safe value, Restart PRO Autotest will turn the RCCB back on. It will not turn on if there is an existing fault. LEDs and an auxiliary contact indicate the operating states. Restart PRO Autotest can be easily turned on or off with a simple toggle switch. Connection (max): 35 sqmm with insulated plug-in protection, top feed.

Key specifications

Length
72 mm
Width
7 mm
mounting style
Top-hat rail
number of poles
4
Item number
20028122

General information

Manufacturer
Gewiss
Category
Residual-current device
Manufacturer no.
GW90923
Release date
16-3-2022

Colour

Colour
White
Exact colour description
White

Circuit Breaker Features

mounting style
Top-hat rail
number of poles
4
Tripping characteristic
A
Rated current
63 A
Rated current
0.03 A
Rated voltage
400 V
voltage type
AC
Residual current (rated differential current)
0.03 A
Protection type (IP code)
IP20

Origin

Country of origin
Portugal

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
72 mm
Width
7 mm

14-day cancellation right
30-day right of return if unopened
24 Months statutory warranty
