Siemens RCCB Type A 40A 3+N-pole 30mA 400V 4mW

Price in EUR including VAT
Ratings
BrandMore from Siemens
Delivered between Thu, 21-5 and Sat, 30-5
free shipping

Product details

Number of poles: 3P + N
Rated current: 40A
Trip sensitivity: 30mA
AC rated voltage: 400 V AC
Mounting type: DIN rail mounting
Range: Sentron
Turn off time: Time delayed
Series: 5SV3
Total width: 77.2mm

Ground fault circuit interrupter series 5SV3. Professional ground fault circuit interrupter from Siemens from the 5SV3 series. Available in 2 or 4 pole versions. Each circuit breaker can be mounted on a DIN rail. All models are very reliable and of excellent quality. Residual current operated overload switch for occupational safety and fire protection. Silicone-free 2 or 4 pole with instantaneous tripping and surge current withstand of over 1 kA. Device lifetime exceeds 10,000 switching cycles. Enclosure rated IP20. Ambient temperature range is -25 to +45 °C. Interrupting time is instantaneous, providing safe protection against residual currents. New type for more convenience with easy and safe installation.

Key specifications

Circuit breaker type
Fault current circuit breaker
Mounting type
Top-hat rail
number of poles
4
Length
70 mm
Width
77.20 mm

General information

Item number
9720282
Manufacturer
Siemens
Category
Residual-current device
Manufacturer No.
5SV3344-6KK01
Release date
24-9-2018

Circuit Breaker Features

Circuit breaker type
Fault current circuit breaker
Mounting type
Top-hat rail
Mounting type
Screw fastening
number of poles
4
Tripping characteristic
A
Rated current
40 A
Rated current
0.03 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
400 V
Residual current (rated differential current)
0.03 A
Protection type (IP code)
IP20

Origin

Country of origin
China

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

CO₂ emissions
18,08 kg
Climate contribution
EUR 0,45

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Length
70 mm
Width
77.20 mm
Height
90 mm
