ABB Stotz S&J T&B Cable Tie TY5244MXR

Manufacturer: ABB Stotz S&J T&B
Description: Cable Tie
Type: TY5244MXR
Band Width: 3.6 mm
Band Length: 368.3 mm
Band Thickness: 1.3 mm
Max. Bundle Diameter: 103 mm
Min. Holding Force: 180 N
Operating Temperature: 1050 °C
Design: Internal serration
Band Closure: Steel tab
Material: Plastic
Material Quality: Polyamide (PA)
Surface Protection: Untreated
UV-Stable according to ASTM D6779: No
Halogen-Free: No
Color: Black
Transparent: No
Fluorescent: No
Labeling Area: None
Removable Closure: No
Mounting Type: None
VG Approval: No
MIL Approval: No
UL Approval: No
Flammability Class of Insulating Material according to UL 94: V2

The black UV-resistant Ty-Rap steel tab cable tie made from polyamide 6.6 is available in various lengths and widths as well as different tensile strengths. This series is specifically designed for outdoor installations. The cable tie is packaged in recyclable plastic bags with Euro holes and contains 2% carbon for military specifications. The corrosion-resistant, non-magnetic steel tab made of stainless steel type 316 in the cable tie head ensures the strongest and safest hold available on the market. The powerful and reliable Ty-Rap can be used under the harshest conditions such as vibrations, heat, or cold. The rounded edges and contours of the head and tie provide user-friendly handling and prevent damage to the insulation of cables and wires from sharp edges or serrations. Additionally, the smooth body without serrated teeth or grooves reduces the number of overstressed areas. The slight nubbing on the inside of the band ensures a secure fit of the tie on the cable bundle. A wide range of accessories complements the product line.
