Hansgrohe ShowerSelect Comfort S1 concealed thermostat

Product details:

• For one consumer
• Large Select button for convenient on/off switching
• Volume control with stop function
• Thermostat cartridge for regulating temperature
• Start/stop valve for operating the consumer
• Flat rosette for more space in the shower
• Round rosette can be adjusted by +/- 3
• Pre-assembled function block for easy installation
• Handles always at the same height regardless of installation depth of the basic body
• Adjustable temperature limiter
• Safety lock at 40 °C
• Thermostat includes on/off button

Technical data:

• Connection type: iBox universal 2 base unit (item no.: 01500180)
• Base unit not included, please order separately
• Max. flow rate at 3 bar: 20.3 l/min
• Min. operating pressure: 1 bar
• Max. operating pressure: 10 bar
• Noise group: I
• Flow rate class: B

Scope of delivery:

• Thermostat
• Function block
• Mounting material and installation instructions.
